The updated DELTA-AX series features improved internal electronics. The newly designed power components ensure high performance and extreme reliability.
Key Features
|
|
Dual mic inputs with combi-jack connections for line inputs.
RCA inputs for easy connection to consumer level audio sources.
Hands-on EQ control for Hi and Low frequencies
Balanced Link output to connect to more active loudspeakers.
Hi Pass filter switch to roll off low end when using in a monitor position.
Not only does this create a solid and durable cabinet, but also contributes to the overall sound.
DELTA-AX is also covered in our most durable and hard wearing Rhino Rock paint finish. This ensures that a DELTA-AX will always look as good as the day you unboxed it.
This fresh design helps to distinguish between the original DELTA-A models and the updated DELTA-AX models.
It is also a logo to be proud of. A logo that lets your audience know that the sound of your even will be of the highest possible quality.
Using convection cooling, DELTA-AX models do not use any internal fans. Fans add to product weight, ambient noise and can lead to unreliability. DELTA-AX has no fans!
The two amplifiers are dedicated to each driver. One amp for the HF and one amp for the LF. This perfect matching ensures that the DELTA-AX is highly efficient, converting as much as the laws of physics allow to be converted into audible output power.
SPECIFICATIONS
| Model Name | DELTA-AX15 |
| System type | Active 2-way bi-amplified |
| Frequency response (+/-3dB) | 50Hz - 20kHz |
| Frequency range (-10dB) | 45Hz - 20kHz |
| Calculated Max SPL @1m | 131dB |
| LF Transducer | 15" |
| Coil size | 3" |
| Impedance | 4Ω |
| HF Transducer | Compression driver |
| Coil size | 2" |
| Exit size | 1.4" |
| Diaphragm material | Titanium |
| Impedance | 8Ω |
| Nominal coverage | 90° x 45° |
| Amplifiers | |
| LF Power amp | 650w RMS Class D |
| HF Power amp | 100w RMS Class D |
| Protection | Power switch on / off mute, Thermal, Low line voltage, DC and Short, Clip limiters |
| Hardware | M10 x 6 |
| 35mm pole socket | |
| 2 x Rubberised 4-way handles | |
| Enclosure | 15mm plywood |
| Rhino rock paint | |
| Grille material | 1.2mm Steel |
| Unpacked | |
| Height | 700mm / 27.56" |
| Width (front) | 446mm / 17.56" |
| Width (rear) | 281.4mm / 11.08" |
| Depth | 406mm / 15.98" |
| Packed | |
| Height | 803mm / 31.6'' |
| Width (front) | 638mm / 25.1'' |
| Width (rear) | 366mm / 14.4'' |
| Depth | 498mm / 19.6'' |
| Weight Net | 33.0kg / 72.6lbs |
| Weight Gross | 38.5kg / 84.7lbs |
| Clearance Item | No |
|---|---|
| Brand | Wharfedale Pro |
