Wharfedale Titan-15D Active Black

Wharfedale Titan-15D Active Black

Wharfedale Pro bring you the next generation of Titan, Titan 15D.

Titan 15D models are bi-amplified, Class D technology is now used for the LF and Class A/B technology is now used for the HF, creating a more efficient and powerful system that is now even lighter than the previous generation.

With the Titan 15D Wharfedale Pro introduce Qubit™, the new powerful and precise 28/56-bit 192kHz DSP processing.

With advanced adaptive multi-band dynamic processing and filtering Qubit helps fine tune your system to sound natural and open. Qubit processing optimises the loudspeaker to provide smooth digital crossover points that are perfectly aligned in terms of phase response and time-domain. Protection is offered in the form of true independent adaptive LF and HF signal limiting that helps protect against thermal damage and driver over excursion.

Qubit has an extended frequency response that goes way beyond the capabilities of our hearing, providing an extended phase response that remains linear throughout our natural hearing range. This enables Titan D to reproduce exceptionally natural transients and exhibit perfectly aligned time-domain characteristics.

Features:

• 2-Way Bi-Amplified

• 15” Custom Designed Moisture Proof Woofer

• Titanium Diaphragm HF Compression Driver

• Qubit™ 28/56-Bit 192kHz DSP Processing

• 350W RMS Class D LF Amplifier Module

• Independent LF and HF Signal Limiting

• Thermal, DC and Short Circuit Fault Protection

• Hi / Low EQ Controls

• 70W RMS Class A/B HF Amplifier Module

• Switchable 90Hz Monitor Filter

• BRO™ Adaptive Bass Response Optimiser

• Combo XLR / 1/4" Jack Balanced Line Level Input and Output

• Rear Panel Mic / Line Switch

• Rear Panel Horn LED Defeat Switch

• Remote Volume Control (Applied voltage controlled)

• Ten M8 Threaded Inserts for Flown Applications

Specifications:

System type : Active 15" 2-way Bi-Amplified

Frequency response +/- 3db : 50-20kHz

Max SPL (Calc) : 125dB

Input connector : XLR - 1/ 4" Combo jack

Dimensions (HxWxD)  : mm 708.3mm x 477.8mm x 401.77mm

Impedance : 4 Ohm

Line Output Connector : Switchable LOOP / MIX Balanced Male XLR

Input A - type : Switchable balanced mic or line level input

Input Connector ; XLR - 1/ 4" Combo jack

Input B - type : Line level input

Input Connectors : Combo jack: 1/4" - XLR / Summed dual RCA jacks

Net weight ( kg / lbs ) : 23.7kg / 52.67lbs

Gross weight ( kg / lbs ) : 26.94kg / 59.27lbs
